Newland NQuire 1000 Manta III Micro Kiosk with 10" Touch Screen with 2D Imager

Overview:

Newland NQuire 1000 Manta III Micro Kiosk with 10 Inch Touch Screen and Android 13
The Newland NQuire 1000 Manta III Micro Kiosk with 10" Touch Screen, 2D CMOS Mega Pixel Imager with Laser aimer (CM6x / Landscape), Android 13 GMS Operating System, 4GB RAM, 64GB Flash, 8MP front camera, 10.1" 1280x800 capacitive Touch Screen Display, Built in 4G module, USB Type C and Type A connectivity, Ethernet RJ45, MicroSD support up to 128GB, Bluetooth 5.2, WiFi and GPS is a compact yet powerful self service solution designed for modern business environments.

Built for interactive applications, this micro kiosk combines a vibrant 10.1 inch touchscreen with high precision barcode scanning and flexible wireless connectivity. Its tablet sized design makes it ideal for countertop placement or shelf mounting across retail stores, hospitality venues, healthcare facilities, manufacturing sites and industrial settings.

Description:

The Newland NQuire 1000 Manta III Micro Kiosk delivers reliable performance in a compact format, combining a 10.1 inch capacitive touchscreen, Android 13 with GMS, and a powerful 2D megapixel barcode scanner with laser aimer. With 4GB RAM, 64GB flash storage, built in 4G, WiFi, Bluetooth 5.2, Ethernet and GPS, it supports seamless connectivity and smooth app performance. Designed for retail, hospitality, healthcare and industrial environments, it enables self service check in, price verification, stock control and secure identification. Optional NFC and MSR modules expand its capabilities for contactless and legacy applications, while flexible mounting options make installation simple in any space.

Features:

Designed for Interactive Self Service and Retail Efficiency
The 10.1 inch 1280 x 800 capacitive touch screen provides a responsive and user friendly interface, making it easy to deploy third party or custom Android applications. Whether used for supermarket price checks, warehouse stock management, hotel self check in or pharmacy information points, the display offers clear visuals and smooth navigation.

Its compact footprint allows installation in both landscape and portrait orientation. With VESA 75 mounting compatibility, integration into existing kiosk setups or wall mounted solutions is straightforward.

Advanced Android 13 Performance
Running on Android 13 with Google Mobile Services, the device offers a secure and familiar environment for application development and deployment. Powered by a 2.0GHz octa core 64 bit processor, the micro kiosk handles multitasking and demanding workflows with ease.

Memory and storage include:

• 4GB RAM for smooth performance
• 64GB internal flash storage
• MicroSD card support up to 128GB for expanded capacity

This combination ensures reliable operation in high traffic commercial environments.

High Precision 1D and 2D Barcode Scanning
At its core, the NQuire 1000 Manta III features Newland megapixel scanning technology with laser aimer, delivering accurate and fast data capture. It supports all major 1D and 2D barcode symbologies, including QR codes, Data Matrix and PDF417.

Typical depth of field performance includes:

• EAN 13 13mil: 70mm to 610mm
• Code 39 5mil: 110mm to 290mm
• PDF417 6.7mil: 110mm to 230mm
• Data Matrix 10mil: 110mm to 260mm
• QR 15mil: 55mm to 410mm

The scanner is optimized to read barcodes displayed on smartphone and tablet screens, supporting digital coupons, mobile tickets and app based loyalty programs.

Comprehensive Connectivity for Modern Workflows
This Android micro kiosk is built for constant connectivity across multiple network environments. Integrated communication options include:

• Built in 4G module with broad global band support
• Dual band WiFi 2.4G and 5G IEEE 802.11 a b g n ac
• Bluetooth 5.2
• Ethernet RJ45 with Power over Ethernet IEEE 802.3 af at
• GPS with AGPS, GLONASS, Beidou and Galileo

Physical interfaces provide additional flexibility:

• 1 x USB Type C
• 1 x USB Type A
• 2 x GPIO
• 1 x expansion slot
• MicroSD card slot

This wide range of connectivity options makes it suitable for fixed installations or locations where wired and wireless networks must work together.

Integrated Camera, Sensors and User Feedback
An 8MP front camera enables identity verification, video communication or image capture for applications that require visual interaction. Built in gravity and infrared sensors enhance device responsiveness and automation.

User notifications are supported through an integrated speaker and multicolour LED indicators, ensuring clear communication during scanning, payment or check in processes.

Optional NFC and MSR for Expanded Applications
For businesses that require secure access control, contactless identification or payment, an optional NFC module supports 13.56MHz RFID standards including ISO14443A B, MIFARE, FeliCa, NFC Forum Tags and ISO15693 . Reader and writer modes are supported, including ID card reading.

An optional MSR module is available for environments that still rely on magnetic stripe technology, helping bridge legacy systems with modern Android based solutions.

Centralized Device Management with Ndevor
The micro kiosk is compatible with Ndevor device management software, enabling centralized control of applications, configurations and updates. This simplifies deployment across multiple units and allows remote troubleshooting from a single management platform.

Built for Demanding Environments
With an IP54 front rating, electrostatic discharge protection up to 12kV air discharge and 6kV direct discharge, and an operating temperature range of -10C to 50C, the NQuire 1000 Manta III is designed to perform reliably in busy commercial and semi industrial settings.

Its dimensions of 251.7 x 173.5 x 32 mm make it compact enough for tight spaces while still providing a large interactive display.

Ideal Applications
This Android micro kiosk is well suited for:

• Retail price checking and self service stations
• Hospitality self check in and guest services
• Healthcare patient registration points
• Manufacturing and warehouse stock control
• Industrial data collection terminals

By combining touchscreen interactivity, enterprise grade barcode scanning and extensive connectivity in a compact format, the Newland NQuire 1000 Manta III Micro Kiosk provides a versatile and future ready solution for businesses seeking to enhance customer engagement and operational efficiency.
