Uniview 4MP OwlView Wise-ISP fixed Warm Light Bullet Network camera with 4mm fixed Lens
- Brand: Uniview
- Product Code: UN-IPC2314LE-ADF40K-WP-L [#22]
- sku: UN-IPC2314LE-ADF40K-WP-L
- Reward Points: 7
- Availability: In Stock ✓ Ready to ship!
- Qty available: 35
R1,326.20 inc. VAT
- Ex VAT: R1,153.22
- Price in reward points: 1327
The specifications below may differ from the model's specifications. Please view the above short specification block to verify which features apply in this model. E&OE.
Overview Summary:
The Uniview 4MP OwlView Wise-ISP Bullet Network Camera with a 4mm fixed lens delivers clear, full-colour surveillance in very low light using ColorHunter and Wise-ISP technology. With warm light illumination up to 30 metres, IP67 weather protection, built-in microphone, PoE support and MicroSD storage up to 512GB, it is a dependable choice for residential and commercial security installations. Buy now for reliable day and night monitoring.Designed for easy integration into modern IP surveillance systems, this camera supports H.265 compression, 120dB true WDR and dual video streams for efficient bandwidth and storage usage. Shop now to upgrade your security system with a high-performance Uniview network camera.
Performance tier: Mid-High Performance
Uses: Home security, business security, office surveillance, warehouse monitoring, retail security, perimeter monitoring, parking area surveillance, outdoor CCTV installations
Overview:
Uniview 4MP OwlView Wise-ISP Fixed Warm Light Bullet Network Camera
Capture sharp, full-color surveillance around the clock with the Uniview 4MP OwlView Wise-ISP Fixed Warm Light Bullet Network Camera. Designed for demanding indoor and outdoor security applications, this network camera combines a high-performance 4MP CMOS sensor, F1.0 large aperture lens, and advanced Wise-ISP technology to deliver exceptional image quality, even in extremely low-light conditions. Its integrated warm white light, intelligent image enhancement, and efficient video compression make it an excellent choice for homes, businesses, warehouses, and commercial properties.
Description:
The Uniview UN-IPC2314LE-ADF40K-WP-L is a professional 4MP IP bullet camera engineered to produce vibrant full-color images in challenging lighting environments. Equipped with OwlView and Wise-ISP technology, it minimizes noise while improving detail and color accuracy. With a built-in microphone, PoE support, IP67 weather protection, microSD storage up to 512GB, and advanced video compression, this camera provides reliable, high-quality surveillance with simplified installation and reduced storage requirements.
Features:
Image Quality for Day and Night Surveillance
The camera features a 1/1.8-inch CMOS sensor paired with an F1.0 large aperture lens, allowing it to capture significantly more light than conventional surveillance cameras. Combined with OwlView ColorHunter and Wise-ISP technology, it delivers bright, detailed color images in scenes where traditional cameras would struggle.
A maximum resolution of 2560 x 1440 ensures crisp video suitable for identifying people, vehicles, and important activity.
Advanced Low-Light Performance
When ambient lighting becomes limited, the integrated warm white illumination provides visibility up to 30 metres. This allows the camera to maintain full-color recording instead of switching to monochrome, helping preserve valuable visual details during nighttime monitoring.
The intelligent Wise-ISP processing further enhances image clarity by reducing smear effects, improving color reproduction, and minimizing image noise.
Reliable Video Performance
The camera supports multiple recording resolutions and frame rates, making it suitable for a wide range of surveillance systems.
Key video capabilities include:
- 4MP (2560 x 1440) at up to 25 fps
- 3MP (2304 x 1296) at up to 30 fps
- Full HD 1080p (1920 x 1080) at up to 30 fps
- Ultra 265, H.265, H.264 and MJPEG compression
- Dual video streams for flexible monitoring
Enhanced Visibility in Difficult Lighting
Bright sunlight and high-contrast scenes are handled effectively using advanced image enhancement technologies.
These include:
- 120 dB True WDR
- 2D and 3D Digital Noise Reduction
- Backlight Compensation (BLC)
- Highlight Compensation (HLC)
- Wise-ISP image optimisation
Together, these technologies help maintain clear images across a wide variety of lighting conditions.
Flexible Surveillance Functions
The camera includes practical monitoring tools that improve both usability and security.
Functions include:
- Built-in microphone for audio recording
- Support for 9:16 corridor mode
- Region of Interest (ROI)
- Up to four on-screen displays (OSDs)
- Up to four privacy masking areas
- Basic intelligent detection
Storage and Network Connectivity
Video can be recorded directly to a microSD card with support for capacities up to 512GB, providing convenient edge storage without requiring continuous network recording.
Networking is provided through a 10/100 Mbps RJ45 Ethernet connection, while Power over Ethernet (PoE) simplifies installation by delivering both power and data over a single network cable.
Built for Outdoor Security
Designed for reliable operation in demanding environments, the camera carries an IP67 weather-resistant rating, protecting it against dust and water ingress. Its adjustable 3-axis mounting mechanism allows flexible positioning for accurate coverage during installation.
Technical Details
- Part Number / SKU: UN-IPC2314LE-ADF40K-WP-L
- 4MP OwlView Wise-ISP bullet network camera
- 1/1.8-inch CMOS image sensor
- 4mm fixed lens
- F1.0 large aperture
- Maximum resolution: 2560 x 1440
- Warm white illumination up to 30m
- Built-in microphone
- Ultra 265, H.265, H.264 and MJPEG compression
- 120 dB True WDR
- ROI support
- Dual video streams
- 2D and 3D DNR
- BLC and HLC
- Basic motion detection
- Up to four OSDs
- Up to four privacy mask areas
- MicroSD card support up to 512GB
- RJ45 10/100 Base-TX Ethernet
- Power over Ethernet (PoE)
- IP67 weather-resistant housing
- 3-axis adjustment
Ideal Applications
The Uniview UN-IPC2314LE-ADF40K-WP-L is well suited for:
- Residential security
- Retail stores
- Office buildings
- Warehouses
- Industrial facilities
- Schools and campuses
- Parking areas
- Commercial perimeter surveillance
Specifications:
| Copyright belongs to the respective owners and brand holders. This table has been carefully researched and generated by ComXpert International CC , however, errors and omissions may occur. Only references to South Africa apply. All products are sourced in South Africa from the official suppliers and the warranty is that of the local supplier. E&OE. This table and our site's content may be used on condition that this notice and link remains intact and unaltered. | |
| Specifications | |
| Product Code | UN-IPC2314LE-ADF40K-WP-L |
| Item | IPC2314LE-ADF40K-WP-L |
| Camera | |
| Max Resolution | 4 MP |
| Sensor | 1/1.8" CMOS |
| Min. Illumination | Color: 0.0003 Lux (F1.0, AGC ON) |
| Shutter | Auto/Manual, 1 to 1/100000 s |
| Adjustment Angle | Pan: 0degrees to 360degrees, Tilt: 0degrees to 90degrees, Rotate: 0degrees to 360degrees |
| S/N | > 52 dB |
| WDR | 120 dB |
| Lens | |
| Focal Length | 4.0 mm |
| Iris Type | Fixed |
| Iris | F1.0 |
| Field of View (H) | 92.1 degrees |
| Field of View (V) | 49.0degrees |
| Field of View (D) | 108.3degrees |
| Lens Type | Fixed |
| DORI | |
| DORI Distance (Lens) | 4 mm |
| DORI Distance (Detect) | 62.1 m (203.7 ft.) |
| DORI Distance (Observe) | 24.8 m (81.4 ft.) |
| DORI Distance (Recognize) | 12.4 m (40.7 ft.) |
| DORI Distance (Identify) | 6.2 m (20.3 ft.) |
| Illuminator | |
| Supplemental Light | Warm light |
| Light On/Off Control | Auto/Manual |
| Illumination Distance (Warm Light) | 30 m (98.4 ft) |
| Video | |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| H.264 Code Profile | Baseline profile, Main profile, High profile |
| Frame Rate | Main Stream: 4 MP (2560 x 1440), max. 25 fps , 3 MP (2304 x 1296), max. 30 fps , 1080P (1920 x 1080), max. 30 fps , 720P (1280 x 720), max. 30 fps |
| Sub Stream: 720P (1280 x 720), max. 30 fps , D1 (720 x 576), max. 30 fps , 640 x 360, max. 30 fps , 2CIF (704 x 288), max. 30 fps , CIF (352 x 288), max. 30 fps | |
| Video Bit Rate | 128 Kbps to 6144 Kbps |
| U-code | Support |
| OSD | Up to 4 OSDs |
| Privacy Mask | Up to 4 areas |
| ROI | Support |
| Video Stream | Dual streams |
| Image | |
| White Balance | Auto, Outdoor, Fine tune, Sodium lamp, Locked, Auto2 |
| Smart Illumination | Support |
| Digital Noise Reduction | 2D/3D DNR |
| Flip | Normal, Flip vertical, Flip horizontal, 180degrees, 90degrees Clockwise, 90degrees Anti-clockwise |
| Dewarping | N/A |
| HLC | Support |
| BLC | Support |
| Defog | Digital defog |
| Image Stabilization | N/A |
| Low Illumination Characteristics | ColorHunter with Wise-ISP |
| Intelligent | |
| People Counting | N/A |
| Statistical Analysis | N/A |
| Events | |
| Basic Detection | Motion detection, Ultra motion detection (based on human body and vehicle detection), Tampering alarm, Audio detection |
| General Function | Watermark, IP address filtering, Access policy, ARP protection, RTSP authentication, User authentication, HTTP authentication |
| Audio | |
| Audio Compression | G.711U, G.711A |
| Audio Bitrate | 64 Kbps |
| Two-way Audio | N/A |
| Suppression | Support |
| Sampling Rate | 8 kHz |
| Storage | |
| Edge Storage | MicroSD, up to 512 GB |
| Network Storage | ANR, NAS (NFS) |
| Network | |
| Protocols | IPv4, IPv6, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS, RTMP, SSL/TLS |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API, SDK |
| User/Host | Up to 32 users. 3 user levels: administrator, common user and operator |
| Security | Password Protection, Strong Password, HTTPS Encryption, Export Operation Logs, Basic and Digest Authentication for RTSP, Digest Authentication for HTTP, TLS 1.2, WSSE and Digest Authentication for ONVIF |
| Client | EZStation, APP |
| Web Browser | Plug-in required live view: IE 10+, Chrome 45+, Firefox 52+, Edge 79+, Plug-in free live view: Chrome 57+, Firefox 58+, Edge 16+ |
| Interface | |
| Audio I/O | N/A |
| Alarm I/O | N/A |
| Serial Port | N/A |
| Built-in Mic | Support |
| Built-in Speaker | N/A |
| WIFI | N/A |
| Network | 1 x RJ45 10 M/100 M Base-TX Ethernet |
| Video Output | N/A |
| Certification | |
| EMC | CE-EMC (EN 55032, EN 61000-3-3, EN IEC 61000-3-2, EN 55035) |
| FCC (FCC 47 CFR part15 B) | |
| Safety | CE LVD (EN 62368-1) |
| UL/CUL (UL 62368-1, CAN/CSA C22.2 No. 62368-1) | |
| Environment | CE-RoHS (2011/65/EU , (EU)2015/863) , WEEE (2012/19/EU) |
| Protection | IP67 (IEC 60529) |
| General | |
| Power | DC 12 V±25%, PoE (IEEE 802.3af) |
| Power Consumption | Max. 3.5 W |
| Power Interface | Ø5.5 mm coaxial power plug |
| Dimensions | 197.8 mm x 73.0 mm x 72.9 mm (7.8" x 2.9" x 2.9") (L x W x H) |
| Weight | 0.30 kg (0.66 lb) |
| Material | Graphene + Plastic |
| Working Environment | -30 degreesC to 60 degreesC (-22 degreesF to 140 degreesF), Humidity: ≤ 95% RH (non-condensing) |
| Storage Environment | -30 degreesC to 60 degreesC (-22 degreesF to 140 degreesF), Humidity: ≤ 95% RH (non-condensing) |
| Surge Protection | 4 KV |
| Reset Button | Support |
| Web Client Language | 13 Languages: English, Simplified Chinese, Polish, German, Russian, French, Korean, Dutch, Czech, Portuguese, Spanish, Spanish (Europe), Italian |
